8 Things You Never Knew About Contact Resistance Meter

Contact Resistance Meter

Testing the electronic equipment is important, as it ensures that they are safe to use and perfectly functional. It is an essential part of the electronics industry, and a contact resistance meter is a helpful asset in such a situation. What is contact resistance, you ask? It is an electrical resistance occurring at the point of contact between components, influenced by the material and connection quality. The machine helps in making the distinction between intentional and incidental contact resistance. It is widely used in industries for power generation, distribution, and manufacturing. So, if you want to detect the electrical integrity and prevent any future failures, then this is the equipment for you. In this post, we will list down the 10 things you never knew about the contact resistance meter.

1. Importance of Contact Resistance

The electrical resistance meter is the point of resistance between the current flow at the interface of the two conductors. With time, corrosion, dust, and mechanical wear can increase the resistance at the contact points. The regular high resistance can lead to reduced electrical efficiency, leading to localized heating and leading to failure of equipment, which can cause fire breakouts. So, when you have the contact resistance meter by your side, you can check the frequency of the high-resistance and regulate it to reduce the chances of future mishaps. It will make the electrical equipment more reliable and efficient.

2. How Does the Contact Resistance Meter Work?

This meter operates using the four-wire(Kelvin) method. This method reduces the need for lead and contact resistance from the measurement, using two wires to inject current and two separate wires to measure the voltage drop across the test object. This meter calculates the resistance using Ohm’s law.

Resistance (R) = Voltage (V)/CURRENT (I)

3. Applications of the Contact Resistance Meters

It is a reliable tool in the electronics industry. It is used for:

• Circuit Breaker Testing: It ensures that the breaker contacts are in good condition.

• Joint Resistance Testing: It detects loose and corroded connections.

• Maintenance: Inspecting the contact quality in high-voltage equipment

• Battery bank interconnect testing

• Transformer tap changer testing

At any of the points where the conductor can in contact can be a weak point and the contact resistance meters helps in verifying these points, so that the problems can be detected.

4.  Standards and Guidelines of the Contact Resistance Meter:

You need to have a high-quality resistance measurement meter so that it can give you precise readings. You cannot afford to have a wrong reading of heavy-duty electrical equipment. It will not just impact the efficiency of the operations, but also can lead to firebreakouts or mishaps. Several industry standards govern the testing of procedures:

• IEEE Std C57.09: For testing the transformer tap changers.

• IEC 62271-100: It is apt for high-voltage circuit breakers.

• NETA ATS/MTS: Guidelines for acceptance and maintenance of testing.

Following these standards will ensure that the operations are safe and by the best industry practices.

5. Types of Contact Resistance Meters

The contact resistance meters vary according to the applications and capabilities:

• Portable Contact Resistance Meter: Lightweight and easy to carry for outdoor operations

• Heavy Current Contact Resistance Meter: It can inject upto 600 Amperes for measuring heavy-duty equipment.

• Multipurpose Contact Resistance Meter: It is an advanced equipment with additional diagnostic features like data logging, Bluetooth, and PC connectivity. It gives precise readings.

With so many options for resistance meters available, you should pick the right one based on the testing requirements,  accuracy level, and environmental conditions.

6. Factors that Can Affect the Accuracy:

There are so many factors that can impact of accuracy of the reading, so it is something that you must keep in mind:

• Temperature: The frequency of resistance increases with the tempature, so it is better to take the reading in normal room temperature.

• Dirt: Dust and contamination can also impact the accuracy of the results, so ensure that the connections are clean and tight.

• Cable Length/ Lead: Too long and of poor quality cables can lead to errors, so always go for the manufacturer’s recommended test leads.

• Electromagnetic Interference: If there is another electric equipment nearby, it can also impact the sensitive low- reading of the equipment.



It is essential to inspect the measurement machine and do the calibration of the machine so that it provides precise readings.

7. Safety Tips to Keep in Mind While Using Contact Resistance Meters:

The resistance meter uses low voltage for testing, but the high voltage involved demands certain safety precautions:

• Wear PPE (Personal protective equipment) during the operations.

• Ensure that the connections are secure before starting testing and reading operations.

• De-energize the equipment before starting the testing, unless the resistance meter supports live testing.

8. Future Trends & Advanced Features:

With the increase in innovations, all the electronic equipment is now equipped with IoT (Internet of Things) for more efficient operations. The same goes for the contact resistance Meters. It consists of:

• Digital Storage: Automatic saving of the results of the reading for analysis and traceability.

• Wireless Communication: Bluetooth or Wi-Fi for the remote control and easy data transfers.

• Touchscreen and Smart Integration Techniques.

All these features enhance the productivity and efficiency of the operations.

Final Words…

The contact resistance meter is not just a resistance measurement tool; it is a massive maintenance powerhouse. It helps in detect the issues which can escalate in future and can lead to mishaps. Thus, it helps in protecting the electrical infrastructure and ensures that the operations keep going smoothly.

The ‘S.B.ELECTROTECH’ you will find a user-friendly design which will revolutionize the way professionals access the contact resistance in the electrical systems. What is more that the compact size and the portability of the machine make it a versatile tool for a wide range of applications.

Frequently Asked Questions:

• How Does the Contact Resistance Meter Work?

The resistance measurement equipment works on the principle of Ohm’s law. The current is passed through the contact, and the resulting voltage drop is measured. Ohm’s law of Resistance (R) = Voltage (V)/CURRENT (I) is used to calculate the final readings.

• What is the Price of a Contact Resistance Meter?

The price of the Contact resistance may vary according to the model that you buy. The advanced model with IoT (Internet of Things) features are expensive and give precise readings. On the other hand, the compact model is more affordable.
