Speciality Valve is a well reputed name among the leading Ball Valve Manufacturers In India, producing high quality. Our quality and precision-made valves are intended for reliable performance in harsh industrial conditions. With an emphasis on quality, reliability and innovation, Speciality Valve manufactures customized ball valve solutions for different industries.

What is the Ball Valve?

A ball valve is a shut off type of valve that regulates the passage of liquids or gases by means of a turning ball with a bore. The valve is open if the hole of the ball is aligned with the flow and closes the flow when turned 90 degrees. Ball valves are noted for their rapid shut off, tight closure and minimal maintenance need.

Main Parts of a Ball Valve

1. Valve Body – The casing that contains all other components in place.
2. Ball – The main part with a bored hole (bore) through its center.
3. Seats – Sealing rings that form a tight seal around the ball to avoid leakage.
4. Stem – It links the ball to the handle or actuator to facilitate rotation.
5. Handle or Actuator – Utilized to rotate the ball manually or automatically.

Working Mechanism

Ball valves work by rotating the handle or actuator 90 degrees, which turn the ball within the valve body. When open, the bore of the ball is in line with the direction of flow and allows unrestricted passage. When closed, the solid face of the ball completely blocks the flow, making it leak proof.

Benefits

• Easy and fast operation
• Prevents wear and tear
• Superb sealing function
• Long-lasting and robust
• Corrosion resistant in aggressive media
• Low pressure loss
• Ideal for complex and custom shape
• Less maintenance

Functions of Ball Valve

1. On/off fluid control
2. Pipeline section isolation
3. Emergency shut-down in high-pressure systems

Types of Ball Valve

1. Wafer Ball Valve
2. Double Block and Bleed Ball Valve
3. Fully Welded Ball Valve
4. Top Entry Ball Valve
5. Trunnion Ball Valve
6. Jacketed Ball Valve
7. Floating Ball Valve
8. Forged Steel Ball Valve
9. Heavy Duty Investment Casting Ball Valve
10. Cast Iron and Cast Steel Ball Valve
11. Investment Casting Ball Valve

Industries

1. Oil and Gas
2. Water and Wastewater
3. Chemical Processing
4. HVAC (Heating, Ventilation, and Air Conditioning)
5. Power Generation
6. Marine and Shipbuilding
7. Pulp and Paper
8. Metallurgy and Mining
9. Automotive
10. Aerospace
11. Agriculture
12. Fire Protection Systems
13. Textile Industry

  Speciality Valve being one of the top Ball Valve Manufacturers In India, provides dependable, high performance valve that adhere to rigorous industry standards. Our ball valve are engineered to provide smooth operation, secure shut off and extended service life for different critical applications.

Description

• Available materials: Cast iron, WCB, WCC, WC6, LCC, LCB, Titanium, SS304, SS316, CF8, CF8M, F55, F51, F53, Monel, Ductile Iron
• Nominal Pressure: PN10 to PN450
• Class: 150-2500
• Size: 1/2”- 48”
• Operations: Lever-operated, electric actuated, pneumatic actuated, gear-operated
• Ends: Flanged, Buttweld, Socket weld, Threaded
